Armstrong Carbon
The carbon A+ System package builder offers a guided shopping experience to assemble your custom foil kit instead of buying a pre-configured package.
Build Custom Carbon Package
THE ESSENCE OF FOILING
Combining rippability, easy pumping and endless glide.
Building on the legacy of our first HA (high aspect) foils initially released in 2021, the new HA range
offers an unprecedented combination of rippability, easy pumping and endless glide that expands the
potential of intermediate to expert surf, downwind and wing foilers. Seven sizes - 580, 680,
780, 880, 980, 1080, 1180cm2 - deliver a full quiver of options. The new HA range is the
essence of foiling.
Compare All Sizes:
HA1180
Wing - Downwind - Surf Foil - Dock Start
The do-it-all wing that intermediate foilers will love. Tailored more for
heavier riders, this wing is designed to perform in all disciplines.
Span: 1066mm | AR: 9.63
Weight:
2.45lb/1.11kg
HA1080
Wing - Downwind - Surf Foil - Dock Start
Everyone's hero foil for small days. This is the first HA front wing for
most people and allows a wide range of skill abilities to get out on the water.
Span: 1020mm | AR: 9.63
Weight:
2.40lb/1.08kg
HA980
Wing - Surf Foil
The all-around foil for lighter weight riders riding at an intermediate
level. For heavier weight riders (above 200lb), this wing is your performance surfoil or
winging front wing.
Span: 974mm | AR: 9.68
Weight:
2.15lb/0.97kg
HA880
Wing - Surf Foil
The magic size of the line-up. It boasts an exceptional amount of glide and
rippability for all disciplines. Imagine the MA1000 and the HA925 having a baby with a lower
bottom end - that's the HA880.
Span: 923mm | AR: 9.68
Weight:
1.95lb/0.88kg
HA780
Wing - Surf Foil
A performance surf foil and winging front wing for medium weight riders.
Intermediate to advanced surf foilers will enjoy this wing in mid size waves, or when
conditions call for more drive and speed down the line.
Span: 870mm | AR: 9.70
HA680
Wing - Tow - Surf Foil
This is a light rider's high-performance winging, surf foiling, and towing
dream front wing. Expert level surf foilers looking to connect with big waves while still
enjoying a low stall speed and maneuverability will find the answer in the HA680.
Span: 818mm | AR: 9.80
HA580
Wing - Tow
This wing is designed to push experienced riders' limits as far as
possible. Experienced riders will enjoy this size for both wing foiling and towing.
STAND OUT PERFORMANCE
A newly developed section shape, outline and profile give the HA range a remarkable “best of both
worlds” ability to carve beautiful lines and easily stay high in the pumping power zone for
maximum wave riding potential.
The foil section is adjusted incrementally at points across the wingspan (evolutive section shape) to
provide a big boost to gliding efficiency and consistent lift at various bank angles and flight
speeds. Riders are enabled to stay up high in the pumping power zone and experience an amazing
carving feel for ultimate wave riding satisfaction.
PERFORMANCE PEDIGREE
Meticulously engineered to push your fun on the water.
The HA range benefits from two years’ worth of research with a leading CFD team in the hydrofoil
sailboat world. These foils turn beautifully and their section is optimised to stay with the wave
allowing smooth flowing connections between swell lines. Excellent lift means riders can drop down
one full size from their previous HA foils for improved carving and speed range while maintaining an
easy low end.
TOP TIER CONSTRUCTION
Built for progression.
High aspect foils experience extreme torsional forces in the water, especially when carving. We’ve
crafted the HA range from premium Toray high and intermediate modulus carbon fibre for an ultra
strong, stiff and lightweight foil that performs exceptionally under the feet of intermediate to
expert riders. The consistency of this layup when combined with our industry-leading manufacturing
quality provides the best in performance and durability.
All Features
All Specifications
|
HA580 |
HA680 |
HA780 |
HA880 |
H9980 |
HA1080 |
HA1180 |
| Area |
580cm2
|
680cm2
|
780cm2
|
880cm2
|
980cm2
|
1080cm2
|
1180cm2
|
| Span |
780mm |
818mm |
870mm |
923mm |
974mm |
1020mm |
1066mm |
| Aspect Ratio |
10.5 |
9.80 |
9.70 |
9.68 |
9.68 |
9.63 |
9.63 |
| Weight |
Coming Soon |
Coming Soon |
Coming Soon |
1.95Lb / 0.88Kg |
2.15Lb / 0.97Kg |
2.40Lb / 1.08Kg |
2.45Lb / 1.11Kg |
A+ System Carbon Mast
Our new A+System is taking strength and durability into the future! See this link for full details.
OUR V2 FULLY TAPERED ONE PIECE MASTS ARE ULTRA SOLID AT THE TOP AND SLICK THROUGH THE WATER DOWN BELOW.
The unique quad c beam core layup delivers a mast with smooth consistent reactive flex, generating sweet handling response and better stability by smoothing out bumps and flexing precisely to drive you through turns.
The V2 masts also feature bombproof zero corrosion Bi Directional Titanium Washer and Titanium T Nut system, which creates a rock solid connection between mast and board.
The V2 mast construction and shape combine to make a mast that will deliver predictably every time.
Mast Length Guide
Choosing the right length mast is important depending on your ability and
intended use.
- 72cm /28.5" The go to Foil Surf mast. An easy all rounder for all foil sports.
- 85cm /33.5" The 'do everything mast' : Intermediate/Advanced. SUP, Downwind, Kite, Wake, and Tow in Surfing.
Mast construction details
- Our unique mast construction was developed in conjunction with composite experts who worked on Team New Zealand America’s Cup foils.
- The quad C beam mast core delivers ‘dynamic reactive flex’ that equates to better strength, stability and control without compromising weight.
- The mast layup is futuristic: at the heart is a multi-piece core that gets wrapped with carbon that has optimised fiber orientation to maximise the potential of the materials. 100% Carbon cloth outer shell ensures a part that is robust and will last.
A+ System Performance Carbon Mast
The Performance Mast range is a clean-sheet design that takes the Armstrong feeling riders know and love to new heights. Sophisticated engineering and top shelf Toray high modulus carbon give these masts a unique combination of efficiency, stiffness and control at speed.
Collaborating with a team of America’s Cup foil engineers, we set out to develop a high performance mast to take us into the future. Our design goal called for a unique blend of strength, stiffness, drag and light weight. Combining CFD analysis with expert insight allowed us to tune each section of the mast from baseplate to fuselage connection for maximum efficiency.
Structural analysis shows that a combination of both high modulus (HM) and intermediate modulus (IM) carbon fibers best distributes loads throughout various sections of the mast. HM's stiffness minimizes flex in the mast's central strut area and IM's high tensile strength caters to the complex shapes of the top plate and fuselage connection.
The result is a top of the line mast consisting of top shelf materials, new mast section, refined baseplate, reduced drag fuselage connection and new construction method. New proprietary titanium M7 mast top hardware follows suit with a strong and lightweight connection to the board.
These masts are designed with a mast rake angle. This fine tunes the board angle relative to the foil for a more comfortable and forgiving ride. It does not change the lifting force or balance of the foil itself, and it does not impact the foil’s “foot pressure” bias front or back. Board rocker also directly determines effective mast rake – boards from different brands have a variety of different rocker lines which influence rake angle – and more rocker in the rear half of board effectively increases mast rake. The 1 degree of rake we’ve placed specifically into the top of the Performance Mast shape provides three main benefits by adjusting the board relative to the foil underwater:
Features
- By bringing the foil closer to 0 degrees when the board is in the water, drag is reduced which makes takeoffs easier.
- Touching down at speed or landing a jump is more forgiving and there’s less chance of crashing headfirst over the board.
- By lifting the board nose slightly (1 degree = 17.46mm/m), mast rake makes it easier to ride fast without catching the nose at steep riding angles.
Package Includes:
- 1x High Aspect Front Wing:
- HA580 (SKU: HA580)
- HA680 (SKU: HA680)
- HA780 (SKU: HA780)
- HA880 (SKU: HA880)
- HA980 (SKU: HA980)
- HA1080 (SKU: HA1080)
- HA1180 (SKU: HA1180)
- 1x A+ Standard or Performance Carbon Mast
- 72cm (SKU: Mast72A)
- 85cm (SKU: Mast85PA)
- Performance 725mm (SKU: MAST725)
- Performance 795mm (SKU: MAST795)
- Performance 865mm (SKU: MAST865)
- Armstrong A+ System TC Fuselage-60cm (SKU: TC60A)
- Armstrong A+ System Tail Wing-Speed 180 (SKU: 4897115082733)
- Armstrong Torx T30 Hand Driver Tool (SKU: ARM23TORXDRIVER)
- Armstrong Torx T30 T-Handle Tool (SKU: ARM19TORX)
- Armstrong A+ System Foil Screw Set (SKU: FSSA)
- Armstrong Foil Bag-X-Large (SKU: XLKITBAG)
