Axis High Performance Speed (HPS) Front Wing

From Axis

High-performance foiling accessible to everyone.

This breakthrough high aspect foil was the result of a long and intensive design and prototyping process that included the development of our new ‘black’ fuselage to incorporate the reduced thickness and chord of the HPS foil section.

The camber of the HPS, a key variable in the lift versus drag trade-off, is also the lowest in the AXIS range.

But while this foil is unashamedly designed for speed and glide, the real achievement is how easy it is to use for almost all levels of rider. Where other brands’ high aspect foils are usually an unstable ‘expert only’ ride, we’ve seen people jump on HPS and rip after a just a few sessions mastering basics on higher lift foils.

This is thanks to the beautifully balanced plan-shape and carefully considered down-turn and twist, that keeps this foil turning freely and handling predictably in all conditions.

AXIS HPS has quickly become our most popular foil for winging for all levels riders once they have the basics down. A true industry benchmark. It’s also making its mark in Downwind, Prone and SUP foiling for faster or more powerful waves. Its high-speed suitability also makes it a natural choice for windsurf and kite foiling.

Package Includes

• Wing
• Wing Cover

• Assembly Hardware Sold Separately

HPS 1050 Carbon Hydrofoil Wing Technical Data

• WINGSPAN: 1050 mm / 41 inches
• MAX CHORD: 170mm
• MEAN AVERAGE CHORD: 123mm
• ASPECT RATIO: 7.55
• ACTUAL AREA 1502 square cm
• VOLUME: 1665 cubic cm / 102 cubic inches

HPS 980 Carbon Hydrofoil Wing Technical Data

• WINGSPAN: 980 mm / 38.6 inches
• MAX CHORD: 160mm / 6.3inches
• ASPECT RATIO: 7.49
• ACTUAL AREA 1323 square cm
• VOLUME: 1379 cubic cm / 84 cubic inches

HPS 930 Carbon Hydrofoil Wing Technical Data

• WINGSPAN: 930 mm / 36.6 inches
• MAX CHORD: 155mm / 6.1 inches
• ASPECT RATIO: 7.34
• ACTUAL AREA 1214 square cm / 188 sq inches
• VOLUME: 1228 cubic cm / 75 cubic inches

HPS 880 Carbon Hydrofoil Wing Technical Data

• WINGSPAN: 880 mm / 34.65 inches
• MAX CHORD: 150mm
• ASPECT RATIO: 7.17
• ACTUAL AREA 1112 square cm
• VOLUME: 1088 cubic cm / 66.42 cubic inches

HPS 830 Carbon Hydrofoil Wing Technical Data

• WINGSPAN: 830 mm / 32.68 inches
• MAX CHORD: 145mm
• ASPECT RATIO: 7.00
• ACTUAL AREA 1014 square cm
• VOLUME: 979 cubic cm / 59.74 cubic inches

HPS 700 Carbon Hydrofoil Wing Technical Data

• WINGSPAN: 700 mm / 27.5 inches
• MAX CHORD: 160mm / 6.3inches
• ASPECT RATIO: 5.63
• ACTUAL AREA 890 square cm / 138 sq inches
• VOLUME: 1060 cubic cm / 65 cubic inches

HPS 650 Carbon Hydrofoil Wing Technical Data

• WINGSPAN: 650 mm / 25.5 inches
• MAX CHORD: 140mm
• ASPECT RATIO: 5.68
• ACTUAL AREA 744 square cm
• VOLUME: 716 cubic cm / 43.75 cubic inches
